Phantom VEO E 340L

Main Features

  • CMOS Sensor
  • 560 x 1.600 Pixel @ 800 fps
  • 512 x 512 Pixel @ 8.570 fps
  • Speed: 290.000 fps
  • Electronical shutter up to 1,0 μs
  • Memory: 18 GB (36 GB / 72 GB optional)
  • Dynamic: 12 Bit
  • Light sensitivity mono/ color:400 / 1.250 ISO
  • Power consumption: 80 Watt
  • Lens mount: Nikon F-Mount, Canon EF-Mount, C-Mount, PL-Mount
  • Size: 127 x 127 x 111 mm
  • Weight: 1,8 kg
  • Shock: 30G mit Verschluss; 100G ohne Verschluss;
  • Vibration: 12 Grms

Phantom VEO® high-speed cameras are robust, compact and packed with numerous functions for a variety of traditional and also more recent applications.

The VEO 340 is a 4 megapixel camera with a throughput of over 3 gigapixels / second (Gpx / s). This enables the recording of up to 800 frames per second (fps) with a resolution of 2560 x 1600 or over 1400 fps with 1080p HD. The maximum speed with reduced resolution is 280,000 fps. With the maximum RAM configuration of 72 GB, the VEO 340 achieves a recording time of 15 seconds at 800 fps.

All Phantom VEO camera models are available in two housing variants, L and S. The L-model contains everything that is needed for traditional software-based acquisition and motion analysis. The S model includes additional signal availability, on-camera controls, rugged connectors and compatibility with removable CFast 2.0 storage media. Both models have 3G HD-SDI and HDMI outputs and a new versatile programmable I / O infrastructure.
