Phantom T4040

Phantom T1340

Main Features

  • Ultra Fast CMOS Sensor
  • 2.048 x 1.952 Pixel @ 3.270 fps
  • 1.920 x 1.080 Pixel @ 6.160 fps
  • 640 x 480 Pixel @ 18.600 fps
  • Max. Speed: 113.514 fps
  • Electronical shutter up to 1,0 μs (499 ns Option)
  • SDI and HDMI video outputs
  • Programmable I/O – assign and define camera signals
  • CineMag V Compatibility (bis zu 8 TB)
  • RAM Memory 36 GB (72 GB, 144GB optional)
  • 10 Gigabit Ethernet (optional)
  • Dynamic: 12 Bit
  • Light sesitifity mono / color: 16.000 / 4.000
  • Power consumption: 160 Watt
  • Lens mount: Nikon F-Mount (supports F & G style lenses), Canon EOS Mount, C-Mount, PL Mount, M42-Mount
  • Size: 12.7 x 12.7 x 20.3 cm
  • Weight: 4,5 kg

The Phantom T1340 is the first member of the new Phantom T-series and the next step in the high-speed camera evolution. The new platform represents high-speed cameras that combine excellent resolution, recording speed and workflow properties in a small and compact housing.

The 4 Mpx sensor works with an image throughput of 13 Gpx / second. The imaging specifications are ideal for motion analysis applications that require data accuracy, such as B. Digital High Speed Correlation (DIC), Particle Image Velocity Measurement (PIV) and stress and strain analysis.

Extended phantom functions enable a wide variety of applications by enabling customized camera settings. Features like:

– “Quiet Mode” to eliminate vibrations for microscopy and 3D measurement techniques
– Stand-alone remote operation with on-camera-controls (OCC)
– Video monitor and CineMag enable outdoor applications
– CineMag supports direct recording of long duration events

Due to its robust construction, the Phantom T1340 can also be used in harsh environments.
