Phantom Miro C211

Phantom Miro C321

Main Features

  • 1,480 fps @ 1,920 x 1,080 (full HD)
  • 8GB/ 16GB RAM
  • 128 GB internal, non-removable CineFlash
  • Internal Battery
  • Linkbox compatible

The newest member of the Phantom Automotive Testing line of cameras brings HD resolution to both on- and off-board testing situations. The Phantom Miro C321, is perfect for confined spaces and delivers excellent picture quality with high light sensitivity. Thanks to the built-in battery and the 128 GB Cine Flash memory, the highest level of data security is guaranteed.

Small & flexible: At 73 mm x 73 mm x 82.5 mm and weighing just over 1 lb. (0.5 kg), the C320 is 3-inch cube small enough to fit into the tightest places. Strategically placed mounting holes make it easy to position, even in difficult and hard to reach places.

Lots of memory: The C321 is available in either 8GB or 16GB of RAM, and comes with an internal, non-removable 128GB CineFlash. The RAM can be separated in up to 63 partitions for back-to-back multi-cine recording. Save 8GB of data into the CineFlash in less than 1.5 minutes, increasing camera up-time. If the experiment disconnects the AC power, the C321 comes equipped with a battery to protect the data until it is saved to non-volatile Flash.



C321 J Mechanical Drawing


C321 Mechanical Drawing


Spectral Response Curve C320


Miro C210 & C210J Manual


Productinfo Phantom C321
