Main Features

  • CMOS Sensor
  • 1.280 x 1.024 Pixel @ 1.800 fps
  • 512 x 512 Pixel @ 3.530 fps
  • Max. Speed: 67.140 fps
  • Electonical shutter up to 5,0 µseconds
  • Memory 8GB or 16 GB (128GB internal, non-removable CineFlash)
  • 1 Gigabit Ethernet
  • Dynanic: 12 bit
  • Light sensitifity mono/ color: 2.500 / 640 ISO
  • Power cosumtion: 12 W / 18 W
  • Lens mount: C-Mount, CS-Mount
  • Size : 73 x 73 x 82,5 mm
  • Weight: 0,54 kg
  • Shock: 170G
  • Vibration: 24 Grms

The Phantom® Miro® C211 is a small, light and versatile digital high-speed camera, perfect for many applications. It has a 12 bit ½-inch CMOS sensor and achieves up to 1,800 frames per second (fps) at full resolution of 1280 x 1024. The Miro C211 has all the features to be a ready companion in any analytical environment.

Small & flexible: At 73 mm x 73 mm x 82.5 mm and weighing just over 1 lb. (0.5 kg), the C211 is 3-inch cube small enough to fit into the tightest places.  Strategically placed mounting holes make it easy to position, even in difficult and hard to reach places. Its small size, pixel format, and C-Mount make it ideal for Microscopy applications. The Miro C211 is compatible with all Miro cables.

Lots of memory: The C211 is available in either 8GB or 16GB of RAM, and comes with an internal, non-removable 128GB CineFlash.  The RAM can be separated in up to 63 partitions for back-to-back multi-cine recording.  Save 8GB of data into the CineFlash in less than 1.5 minutes, increasing camera up-time.  If the experiment disconnects the AC power, the C211 comes equipped with a battery to protect the data until it is saved to non-volatile Flash.

Motion Analysis:  The Miro C211 benefits from Vision Research Phantom Camera Control (PCC) software, including the motion analysis tools in the software.  PCC can perform timing, position, distance, velocity, angle and angular speed measurements and provide a full suite of calculations on the data.
